Creating a Contact Facet in xDB Sitecore 9 & xConnect Magic!

Akshay Sura - Partner

25 Aug 2018

In this video, I am going to walk you through how to create a contact facet in xDB and use xConnect to add that facet value for an existing contact in Sitecore 9 Update 2.

Useful links:

  • Getting Started with xConnect
  • xConnect: Adding custom facets in Sitecore 9
  • GitHub Repo: https://github.com/konabos/xConnectLoyalty

If you have any questions or concerns, please get in touch with me. (@akshaysura13 on Twitter or on Slack).

1. using Sitecore . XConnect ;
2.
3. namespace Konabos . XConnect . Loyalty . Model . Facets
4. {
5. public class LoyaltyCommerceFacet : Facet //Contact facet to store the Commerce CustomerId - read only
6. {
7. public const string DefaultFacetKey = "LoyaltyCommerceFacet" ;
8.
9. public string CommerceCustomerId { get ; set ; }
10. }
11. }
12. using Sitecore . XConnect ;
13.
14. namespace Konabos . XConnect . Loyalty . Model . Facets
15. {
16. [ FacetKey ( DefaultFacetKey )]
17. public class LoyaltyPointsFacet : Facet //Contact facet to store the points earned and spent based on the minion processing - read only
18. {
19. public const string DefaultFacetKey = "LoyaltyPointsFacet" ;
20.
21. public int PointsEarned { get ; set ; }
22. public int PointsSpent { get ; set ; }
23. }
24. }
25. using Konabos . XConnect . Loyalty . Model . Facets ;
26. using Sitecore . XConnect ;
27. using Sitecore . XConnect . Schema ;
28.
29. namespace Konabos . XConnect . Loyalty . Model . Models
30. {
31. public class LoyaltyModel
32. {
33. public static XdbModel Model { get ; } = BuildModel ();
34.
35. private static XdbModel BuildModel ( )
36. {
37. XdbModelBuilder modelBuilder  = new XdbModelBuilder ( "LoyaltyModel" , new XdbModelVersion ( 1 , 0 ));
38.
39. modelBuilder . DefineFacet < Contact , LoyaltyPointsFacet >( FacetKeys . LoyaltyPointsFacet );
40. modelBuilder . DefineFacet < Interaction , LoyaltyOrderInfoFacet >( FacetKeys . LoyaltyOrderInfoFacet );
41. modelBuilder . DefineFacet < Contact , LoyaltyCommerceFacet >( FacetKeys . LoyaltyCommerceFacet );
42.
43. modelBuilder . ReferenceModel ( Sitecore . XConnect . Collection . Model . CollectionModel . Model );
44.
45. return modelBuilder . BuildModel ();
46. }
47. }
48. public class FacetKeys
49. {
50. public const string LoyaltyOrderInfoFacet = "LoyaltyOrderInfoFacet" ;
51. public const string LoyaltyPointsFacet = "LoyaltyPointsFacet" ;
52. public const string LoyaltyCommerceFacet = "LoyaltyCommerceFacet" ;
53. }
54. }
55. using System . IO ;
56.
57. namespace Konabos . XConnect . Console
58. {
59. class Program
60. {
61. static void Main ( string [] args )
62. {
63. System . Console . WriteLine ( "Generating your model..." );
64.
65. var model  = Konabos . XConnect . Loyalty . Model . Models . LoyaltyModel . Model ;
66.
67. var serializedModel  = Sitecore . XConnect . Serialization . XdbModelWriter . Serialize ( model );
68.
69. File . WriteAllText ( "c:\temp\" + model.FullName + " . json ", serializedModel);
70.
71. System.Console.WriteLine(" Press any key to  continue ! Your model  is here : " + " c : \temp\ "  + model . FullName + " .json " );
72. System . Console . ReadKey ();
73. }
74. }
75. }
76. using System ;
77. using System . Collections . Generic ;
78. using System . Threading . Tasks ;
79. using Konabos . XConnect . Loyalty . Model . Facets ;
80. using Konabos . XConnect . Loyalty . Model . Models ;
81. using Sitecore . XConnect ;
82. using Sitecore . XConnect . Client ;
83. using Sitecore . XConnect . Client . WebApi ;
84. using Sitecore . XConnect . Collection . Model ;
85. using Sitecore . XConnect . Schema ;
86. using Sitecore . Xdb . Common . Web ;
87.
88. namespace Konabos . XConnect . ConsoleTester
89. {
90. class Program
91. {
92. static void Main ( string [] args )
93. {
94. Task . Run ( async () => { await ProcessCustomers (); }). Wait ();
95.
96. System . Console . ForegroundColor = ConsoleColor . DarkGreen ;
97. System . Console . WriteLine ( "" );
98. System . Console . WriteLine ( "END OF PROGRAM." );
99. System . Console . ReadKey ();
100. }
101.
102. private static async Task ProcessCustomers ( )
103. {
104. CertificateWebRequestHandlerModifierOptions options  =
105. CertificateWebRequestHandlerModifierOptions . Parse ( "StoreName=My;StoreLocation=LocalMachine;FindType=FindByThumbprint;FindValue=BC9B7186102910E8F34EE8D9F38138203F7555BA" );
106.
107. var certificateModifier  = new CertificateWebRequestHandlerModifier ( options );
108.
109. List < IHttpClientModifier > clientModifiers  = new List < IHttpClientModifier >();
110. var timeoutClientModifier  = new TimeoutHttpClientModifier ( new TimeSpan ( 0 , 0 , 20 ));
111. clientModifiers . Add ( timeoutClientModifier );
112.
113. var collectionClient  = new CollectionWebApiClient ( new Uri ( "https://cateringdemo.xconnect.dev.local/odata" ), clientModifiers , new [] { certificateModifier  });
114. var searchClient  = new SearchWebApiClient ( new Uri ( "https://cateringdemo.xconnect.dev.local/odata" ), clientModifiers , new [] { certificateModifier  });
115. var configurationClient  = new ConfigurationWebApiClient ( new Uri ( "https://cateringdemo.xconnect.dev.local/configuration" ), clientModifiers , new [] { certificateModifier  });
116.
117. var cfg  = new XConnectClientConfiguration (
118. new XdbRuntimeModel ( LoyaltyModel . Model ), collectionClient , searchClient , configurationClient );
119.
120. try
121. {
122. await cfg . InitializeAsync ();
123. }
124. catch ( XdbModelConflictException ce )
125. {
126. System . Console . WriteLine ( "ERROR:" + ce . Message );
127. return ;
128. }
129.
130. using ( var client  = new XConnectClient ( cfg ))
131. {
132. try
133. {
134. //search for an existing contact based on an identifier
135. IdentifiedContactReference reference  = new IdentifiedContactReference ( "CommerceUser" , "Storefront\sakshay13@gmail.com" );
136. Contact existingContact  = client . Get < Contact >( reference , new ContactExpandOptions ( new string [] { PersonalInformation . DefaultFacetKey , LoyaltyPointsFacet . DefaultFacetKey , LoyaltyCommerceFacet . DefaultFacetKey }));
137.
138. if ( existingContact  != null )
139. {
140. LoyaltyPointsFacet loyaltyPointFacet  = existingContact . GetFacet < LoyaltyPointsFacet >( LoyaltyPointsFacet . DefaultFacetKey );
141.
142. if ( loyaltyPointFacet  == null )
143. {
144. loyaltyPointFacet  = new LoyaltyPointsFacet ()
145. {
146. PointsEarned = 33 ,
147. PointsSpent = 44
148. };
149. client . SetFacet < LoyaltyPointsFacet >( existingContact , LoyaltyPointsFacet . DefaultFacetKey , loyaltyPointFacet );
150.
151. client . Submit ();
152. }
153.
154. LoyaltyCommerceFacet loyaltyCommerceFacet  = existingContact . GetFacet < LoyaltyCommerceFacet >( LoyaltyCommerceFacet . DefaultFacetKey );
155. if ( loyaltyCommerceFacet  == null )
156. {
157. loyaltyCommerceFacet  = new LoyaltyCommerceFacet ()
158. {
159. CommerceCustomerId = "001"
160. };
161. client . SetFacet < LoyaltyCommerceFacet >( existingContact , LoyaltyCommerceFacet . DefaultFacetKey , loyaltyCommerceFacet );
162.
163. client . Submit ();
164. }
165. }
166.
167. //Get all contacts and process them
168. //var contacts = client.Contacts.WithExpandOptions(new ContactExpandOptions(PersonalInformation.DefaultFacetKey)).ToEnumerable();
169. ////var contacts = client.Contacts.ToEnumerable();
170. //foreach (var contact in contacts)
171. //{
172. // Console.WriteLine("Contact ID: " + contact.Id.ToString());
173.
174. // var rsonalInformationFacet = contact.GetFacet<PersonalInformation>();
175. // PersonalInformation personalInformationFacet = contact.GetFacet<PersonalInformation>(PersonalInformation.DefaultFacetKey);
176. // if (personalInformationFacet != null)
177. // Console.WriteLine("Contact Name: " + personalInformationFacet.FirstName + " " + personalInformationFacet.LastName);
178. // else
179. // Console.WriteLine("Contact Personal Information not found.");
180.
181. // LoyaltyPointsFacet loyaltyPointFacet = contact.GetFacet<LoyaltyPointsFacet>(LoyaltyPointsFacet.DefaultFacetKey);
182.
183. // if (loyaltyPointFacet == null)
184. // {
185. // Console.WriteLine("Contact Loyalty Information not found.");
186. // LoyaltyPointsFacet visitorInfo = new LoyaltyPointsFacet()
187. // {
188. // PointsEarned = 0,
189. // PointsSpent = 0
190. // };
191. // client.SetFacet<LoyaltyPointsFacet>(contact, LoyaltyPointsFacet.DefaultFacetKey, visitorInfo);
192. // }
193. // else
194. // Console.WriteLine("Contact Loyalty Found: " + loyaltyPointFacet.PointsEarned);
195.
196.
197. //}
198.
199. Console . ReadLine ();
200. }
201. catch ( XdbExecutionException ex )
202. {
203. System . Console . WriteLine ( "ERROR:" + ex . Message );
204. return ;
205. }
206. }
207. }
208. }
209. }
